Halowill
SFP-1.25G-BIDI-40KM
Compatible:Cisco
Quantity:
- LC Duplex Type, VCSEL+PIN
- Double Bandwidth by Using Only One Fiber
- For Fast Ethernet and Data Center
- Hot Pluggable SFP MSA Compliant
The 1000BASE-BIDI SFP transceiver provides up to 40km of 1000Base-BIDI throughput over single-mode fiber (SMF) using 1310nm-TX/1550nm-RX wavelengths via LC simplex connectors. This bi-directional unit must be used with another transceiver or network equipment of complementary wavelengths. It provides 1000BASE Ethernet connectivity options for Fast Ethernet, Telecom and Data Centers.
CERTIFICATES
Our products have passed authoritative certification and complied with international quality standard
Description |
|
| Part Number | SFP-1.25G-BIDI-40KM |
| Vendor Name | HaloWill |
| Form Factor | SFP |
| Wavelength | 1310nm-TX/1550nm-RX & 1550nm-TX/1310nm-RX |
| Connector | LC Duplex |
| Transimitter Type | DFB BIDI |
| Data Rate | 1.25Gbps |
| Reach | 40KM |
| Cable Type | SMF |
| DDM/DOM | Supported |
| TX Power | -5-0dBm |
| Receiver Sensitivity | <-24dBm |
| Receiver Overload | -3dBm |
| Receiver Type | PIN |
| Operating Temperature | 0 to 70°C |
| Extinction Ratio | >8dB |
| Host FEC | Supported |
| BER | 1E-12 |
| Warranty | 3 years |
| Protocols | IEEE 802.3ah-2004, IEEE 802.3z, SFF-8472, SFP MSA (INF-8074i) Compliant |
APPLICATION
SFP transceivers are suitable for different 1.25G network solutions
1.25G PRODUCTS FOR:
Fast Ethernet, Telecom and Data Centers
QUALITY CONTROL
Professional QC team and dvanced testing equipments contribute a lot to the reliable quality of products. Every optical transceiver has been tested strictly before delivery to avoid after-sales issues.
